Ctrl + Alt + T
cd /home/user/.goldendict/styles/
mkdir Dark
cd Dark
touch qt-style.css
pico qt-style.css
Saturday, July 31, 2021
Friday, July 30, 2021
Nikon DSLR not listed as mounted device in Kubuntu
Accessing Nikon DSLR with Dolphin, Gwenview
Camera doesn’t connect as a mass storage device
Gwenview can't import download images from camera
Dolphin do not see Nikon D7000 as mass storage
URL cannot be listed
camera:/
Monday, July 26, 2021
Run script on startup in Ubuntu
Ctrl + Alt + T
cd /home/user/.config/
mkdir autostart
cd /home/user/.config/autostart
touch myscript.desktop
pico myscript.desktop
[Desktop Entry]
Name= myscript
Type=Application
Exec=/home/user/myscript/myscript.sh
chmod +x myscript.sh
reboot
Sunday, July 25, 2021
Configuring X server for the NVIDIA Driver
/usr/share/X11/xorg.conf.d/10-nvidia.conf
Section "OutputClass"
Identifier "nvidia"
MatchDriver "nvidia-drm"
Driver "nvidia"
Option "AllowEmptyInitialConfiguration"
Option "Coolbits" "28"
ModulePath "/usr/lib/x86_64-linux-gnu/nvidia/xorg"
EndSection
Change NVIDIA graphic card power limit:
nvidia-smi -i 0 -q
sudo nvidia-smi -i 0 -pl 75
Warning: persistence mode is disabled on device 00000000:26:00.0. See the Known Issues section of the nvidia-smi(1) man page for more information. Run with [--help | -h] switch to get more information on how to enable persistence mode.
sudo nvidia-smi -i 0 -pm ENABLED
Enabled persistence mode for GPU 00000000:26:00.0.
All done.
nvidia-smi -i 0 -q
nvidia-smi --query-gpu=power.draw --format=csv,noheader,nounits // current consumption in watts
watch -n 1 nvidia-smi --query-gpu=power.draw --format=csv,noheader,nounits // -n 1 => every sec
watch -n 1 nvidia-smi --query-gpu=power.draw --format=csv,noheader,nounits >> //media/user/directory/power_log.txt && truncate -s 100M /media/user/directory/power_log.txt
sudo nano gpu_power_monitor.sh
#!/bin/bash
LOG_FILE="/media/user/directory/gpu_power_log.txt"
MAX_SIZE_MB=10
while true; do
POWER=$(nvidia-smi --query-gpu=power.draw --format=csv,noheader,nounits)
TEMPERATURE=$(nvidia-smi --query-gpu=temperature.gpu --format=csv,noheader,nounits)
CURRENT_TIME=$(date "+%Y-%m-%d %H:%M:%S")
echo "P: $POWER W, T: $TEMPERATURE C $CURRENT_TIME" >> "$LOG_FILE"
echo "P: $POWER W, T: $TEMPERATURE C $CURRENT_TIME"
FILE_SIZE=$(du -m "$LOG_FILE" | cut -f1)
if [ "$FILE_SIZE" -gt "$MAX_SIZE_MB" ]; then
sed -i '1d' "$LOG_FILE"
fi
sleep 1
done
LOG_FILE="/media/user/directory/gpu_power_log.txt"
MAX_SIZE_MB=10
while true; do
POWER=$(nvidia-smi --query-gpu=power.draw --format=csv,noheader,nounits)
TEMPERATURE=$(nvidia-smi --query-gpu=temperature.gpu --format=csv,noheader,nounits)
CURRENT_TIME=$(date "+%Y-%m-%d %H:%M:%S")
echo "P: $POWER W, T: $TEMPERATURE C $CURRENT_TIME" >> "$LOG_FILE"
echo "P: $POWER W, T: $TEMPERATURE C $CURRENT_TIME"
FILE_SIZE=$(du -m "$LOG_FILE" | cut -f1)
if [ "$FILE_SIZE" -gt "$MAX_SIZE_MB" ]; then
sed -i '1d' "$LOG_FILE"
fi
sleep 1
done
chmod +x gpu_power_monitor.sh
./gpu_power_monitor.sh
Wacom tablet cursor offset not working correctly in OBS
Ctrl + Alt + T
cd /usr/share/applications/
sudo pico com.obsproject.Studio.desktop
Change Exec=obs
to Exec=QT_XCB_TABLET_LEGACY_COORDINATES=1 obs
Write terminal output of a command to a file
|| visible in terminal || visible in file || existing
Syntax || StdOut | StdErr || StdOut | StdErr || file
==========++==========+==========++==========+==========++===========
> || no | yes || yes | no || overwrite
>> || no | yes || yes | no || append
|| | || | ||
2> || yes | no || no | yes || overwrite
2>> || yes | no || no | yes || append
|| | || | ||
&> || no | no || yes | yes || overwrite
&>> || no | no || yes | yes || append
|| | || | ||
| tee || yes | yes || yes | no || overwrite
| tee -a || yes | yes || yes | no || append
|| | || | ||
n.e. (*) || yes | yes || no | yes || overwrite
n.e. (*) || yes | yes || no | yes || append
|| | || | ||
|& tee || yes | yes || yes | yes || overwrite
|& tee -a || yes | yes || yes | yes || appendRemove boot option in bios boot menu UEFI
user@PC:~$ sudo fdisk -l
[sudo] password for user:
Disk /dev/nvme0n1: 238,49 GiB, 256060514304 bytes, 500118192 sectors
Disk model: TS256GMTE110S
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: gpt
Disk identifier: 6A76AEF7-D60C-4CA8-A4F2-9053CCDB5F29
Saturday, July 24, 2021
Wacom tablet not working in Oracle VM VirtualBox
Ctrl + Alt + T
cd /usr/share/applications/
sudo pico virtualbox.desktop
Change Exec= VirtualBox %U
to Exec=QT_XCB_TABLET_LEGACY_COORDINATES=1 VirtualBox %U
Friday, July 23, 2021
Thursday, July 22, 2021
No access to shared folders on Windows
No access to shared folders on Ubuntu from Windows
This works on Windows Vista, Windows 7, Windows 8.1 and Windows 10:
Go to Network and Sharing Center.
Change advanced sharing settings
All networks (at the bottom)
Turn off password protected sharing
Install Google Chrome in Ubuntu Terminal
wget https://dl.google.com/linux/direct/google-chrome-stable_current_amd64.debsudo dpkg -i google-chrome-stable_current_amd64.debwine folder not found after install wine /home/user/.wine/
wine --version
winecfg
wine control
wine explorer
wine program.exe
Wednesday, July 21, 2021
Ubuntu Software and Updates Settings
Show info about current operation system - OS:
cat /etc/*release
cat /etc/*ease
hostnamectl // system info
lsb_release -a // system information
smb.conf - samba configuration - ubuntu mounted ntfs drive
sudo apt update
sudo apt install samba
sudo apt install smbclient
smbd -V
sudo smbstatus
sudo service smbd restart
sudo service nmbd restart
sudo service smbd status
sudo service nmbd status
sudo systemctl enable smbd.service nmbd.service
sudo service smbd stop
sudo service nmbd stop
sudo nano /etc/samba/smb.conf // old configuration files... see link on previous line!!!
Thursday, July 15, 2021
Яйко-Ілемське чи Мізунка?
12.07.2021 виїзд електричкою на Стрий, пересадка на автобус і я в Долині! Автостанція закрита, жодних розкладів - супер! Сиджу на вокзалі, думаю, гадаю, куди податися: Мислівка чи Новий Мізунь? Зважаючи на хмарки, які інтенсивно скупчувалися на небосхилі, вирішив їхати в Мислівку, бо добре знаю, що таке дощі на Мізунці. Там зграї комарів, мух, слизька вузькоколійка та важкий брід + маршрут сам по собі не дуже цікавий. Не встиг вийти з автобуса Львів-Хуст у Мислівці, як почався дощ. Вгадав! Шлях до Яйка-Ілемського незмінний, але перед підйомом на полонину Мшану його частково спердолили лісоруби + природа допомогла: трапився 1 серйозний смерековий бурелом.
13.07.2021 йду глянути на хатку під Яйко-Ілемське. Краще б я цього не робив, але загалом більш-менш приємно прогулявся. Ось залишки колиби під Яйком-Ілемським:
Saturday, July 3, 2021
Linux standard directories and their contenrs
/bin |
Core operating system commands |
/boot |
Boot loader, kernel, and files needed by the kernel |
/compat |
On FreeBSD, files and libraries for Linux binary compatibility |
/dev |
Device entries for disks, printers, pseudo-terminals, etc. |
/etc |
Critical startup and configuration files |
/home |
Default home directories for users |
/lib |
Libraries, shared libraries, and commands used by /bin and /sbin |
/media |
Mount points for filesystems on removable media |
/mnt |
Temporary mount points, mounts for removable media |
/opt |
Optional software packages (rarely used, for compatibility) |
/proc |
Information about all running processes |
/root |
Home directory of the superuser (sometimes just /) |
/run |
Rendezvous points for running programs (PIDs, sockets, etc.) |
/sbin |
Core operating system commands a |
/srv |
Files held for distribution through web or other servers |
/sys |
A plethora of different kernel interfaces (Linux) |
/tmp |
Temporary files that may disappear between reboots |
/usr |
Hierarchy of secondary files and commands |
/usr/bin |
Most commands and executable files |
/usr/include |
Header files for compiling C programs |
/usr/lib |
Libraries; also, support files for standard programs |
/usr/local |
Local software or configuration data; mirrors /usr |
/usr/sbin |
Less essential commands for administration and repair |
/usr/share |
Items that might be common to multiple systems |
/usr/share/man |
On-line manual pages |
/usr/src |
Source code for nonlocal software (not widely used) |
/usr/tmp |
More temporary space (preserved between reboots) |
/var |
System-specific data and a few configuration files |
/var/adm |
Varies: logs, setup records, strange administrative bits |
/var/log |
System log files |
/var/run |
Same function as /run; now often a symlink |
/var/spool |
Spooling (that is, storage) directories for printers, mail, etc. |
/var/tmp |
More temporary space (preserved between reboots) |
Поширені помилки Ford Mondeo MK4 2014
Ford BS71-13A602-BD
Ford BS71-13A602-BC
JX7B13A602DA, 32D1884T, 1717230, 1738520, 354997081, 9EL354997081, 1 764 009
(OK) [11:17:47.895] Read system monitor status has been started
(OK) [11:17:47.932] Malfunction Indicator Lamp (MIL) Status: Off
(WARN) [11:17:47.935] Misfire monitoring: Not supported
(OK) [11:17:47.937] Fuel system monitoring: Complete
(OK) [11:17:47.939] Comprehensive component monitoring: Complete
(WARN) [11:17:47.941] Catalyst monitoring : Not supported
(WARN) [11:17:47.943] Heated catalyst monitoring : Not supported
(WARN) [11:17:47.945] Evaporative system monitoring: Not supported
(OK) [11:17:47.947] Secondary air system monitoring: Complete
(WARN) [11:17:47.950] A/C system refrigerant monitoring: Not supported
(OK) [11:17:47.952] Oxygen sensor monitoring: Complete
(OK) [11:17:47.954] Oxygen sensor heater monitoring: Complete
(OK) [11:17:47.956] EGR system monitoring: Complete
(OK) [11:17:56.140] Test completed successfully, no errors found
(WARN) [18:12:40.035] Checking FTDI #1:A50285BI...
(OK) [18:12:50.763] Connection to adapter has been established: FTDI #1:A50285BI
(OK) [18:12:50.764] Adapter: STN1170 v3.3.1 (ELM327 v1.3a)
(ERR) [18:12:50.844] This adapter uses ********** STN chip
(OK) [18:12:51.157] Connection to vehicle has been established
(OK) [18:13:00.799] Vehicle: Ford Mondeo Duratorq Turbo Diesel Common Rail Injection Stage V 2.0L 2014 ( 2011 MY ), VIN: *****************
(OK) [18:13:03.953] Found module: PCM - Powertrain Control Module
(WARN) [18:13:04.117] DTCs in PCM: P003A:00-28
(OK) [18:13:04.224] Found module: OBDII - On Board Diagnostic II
(OK) [18:13:04.466] Found module: SASM - Steering Angle Sensor Module
(OK) [18:13:04.754] Found module: ABS - Antilock braking system
(WARN) [18:13:05.114] DTCs in ABS: B1B69:16-08
(OK) [18:13:05.134] Found module: RCM - Restraint Control Module
(OK) [18:13:06.403] Found module: PSCM - Power Steering Control Module
(OK) [18:13:06.974] Found module: BCMii - Body Control Module
(OK) [18:13:07.104] Found module: SRM - Speech Recognition Module
(OK) [18:13:07.181] Found module: PDM - Passengers Door Control Unit
(WARN) [18:13:07.463] DTCs in PDM: U2101:00-28
(OK) [18:13:07.485] Found module: DDM - Drivers Door Module
(OK) [18:13:07.620] Found module: HVAC - Heating Ventilation Air Conditioning
(OK) [18:13:07.697] Found module: ACM - Audio Control Module
(OK) [18:13:08.342] Found module: IPC - Instrument Panel Control Module
(WARN) [18:13:08.494] DTCs in IPC: U0401:68-2A, U0416:68-AE
===PCM DTC P003A:00-28===
Code: P003A - Turbocharger/Supercharger Boost Control A Position Exceeded Learning Limit
https://mondeoclub.ru/forums/topic/142781/
Status:
- Previously Set DTC - Not Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
Module: Powertrain Control Module
Freeze Frame :
-GLOBTIM: 244546761 s - Global real time
-TOTDIST: 229666.0 km - Total Distance
-MAINECUV: 13.50 V - Main ECU voltage supply
-ESTSERUN: No - Engine status - engine running
-ESTSECRK: No - Engine status - engine in crank
-INCARTMP: 27 °C - In car temperature
-OUTTMP: 4 °C - External Temperature From Sensor
===END PCM DTC P003A:00-28===
===ABS DTC B1B69:16-08===
Code: B1B69 - 12 Volt Supply Circuit
Additional Fault Symptom:
- Circuit Voltage Below Threshold
Status:
- Previously Set DTC - Not Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
Module: Antilock braking system
===END ABS DTC B1B69:16-08===
===PDM DTC U2101:00-28===
Code: U2101 - Control Module Configuration Incompatible
https://www.autocodes.com/u2101_ford.html Body Control Module (BCM) ABS
This code will also appear when updating the A-3 to A-12 map card. Simply erase code or after driving approx 100 miles it will reset itself. Also if the ignition key cylinder ( not the switch) starts wearing as mine did it will throw the U2-101 code. This code does not affect the operation of the vehicle or throw a "check engine" light.
Status:
- Previously Set DTC - Not Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
Module: Passengers Door Control Unit
Freeze Frame :
-GLOBTIM: 265782172 s - Global real time
-TOTDIST: 241976.0 km - Total Distance
-MAINECUV: 11.50 V - Main ECU voltage supply
===END PDM DTC U2101:00-28===
===IPC DTC U0401:68-2A===
Code: U0401 - Invalid Data Received from ECM/PCM A
https://www.troublecodes.net/ucodes/u0401/ ABS PCM TCM BCM
Additional Fault Symptom:
- Event Information
Status:
- DTC Present at Time of Request
- Malfunction Indicator Lamp is Off for this DTC
Module: Instrument Panel Control Module
===END IPC DTC U0401:68-2A===
===IPC DTC U0416:68-AE===
Code: U0416 - Invalid Data Received From Vehicle Dynamics Control Module
https://www.troublecodes.net/ucodes/u0416/ ABS PCM
Additional Fault Symptom:
- Event Information
Status:
- DTC Present at Time of Request
- Malfunction Indicator Lamp is On for this DTC
Module: Instrument Panel Control Module
===END IPC DTC U0416:68-AE===
Friday, July 2, 2021
JavaScript Cheatsheet
let – block-scoped var – function-scoped === NEVER USE!!!
Prefer const userNa = and template literal `I ${userNa} pay ${bill + tip}`; No need for \n === newline in ` `. const value can be changed in array. only primitive const value is immutable
Use ===, !==. Do not use ==, !=
'Let\'s go!' // with ' ' escaping with \ should be used
'Tommy is ' + age + ' years old.'; // String concatenation
`Tommy is ${age} years old.`; // String interpolation
https://developer.mozilla.org/en-US/docs/Learn/Getting_started_with_the_web/JavaScript_basics
Data types: Number (always float 10.0, 5.0), String, Boolean, Null, Undefined, BigInt (integers Number can't use) // check type with typeof
type conversion – manual conversion
type coercion – automatic covenrsion by JS – AVOiD!!!
Number(constName): converts string to number but original value still be a string
String(constName)
NaN – Not a Number === invalid number
Falsy values: 0, ' ', undefined, null, NaN converted to Boolean(constName); others are truethy
Linux Console Tutorial
This document is intended to provide a foundation of skills for using Linux in console or shell mode. The reader is not expected to have any prior knowledge of how Linux works, although in this case the reader should at least look through Linux Concepts and Running Commands before moving on to the Command Reference. The Command Reference introduces the core set of Linux commands categorized by the type of functionality they provide. The final section on Advanced Features illustrates several techniques that will help you get the most out of Linux.
Заливає свічки AUDI 80 B4 1994 2.0 бензин не заводиться
Одного чудового дня AUDI 80 B4 1994 із 2-літровим моноінжектором не заводиться. Іскри є, акумулятор заряджений, стартер крутить, інжектор поливає свічки пальним, а толку...
Як визначив причину проблеми? На холодному авто
1) поміряв опір контактів датчика температури вхідного повітря - датчик температуры всасываемого воздуха (крайні лівий і правий контакти під повітряним фільтром з боку акумулятора на блоці інжектора - клема на 4 піни),
2) поміряв опір на сірому 3-контактному датчику температури (подає сигнал на табло, знаходиться на блоці циліндрів - див. патрубок антифризу) та
3) поміряв опір на блакитному 2-контактниому датчику температури антифризу (на блоці циліндрів - див. патрубок антфризу).
При температурі навколишнього середовища +25, опір на датчику температури вхідного повітря становив 0,9 кОм, на сірому 3-контактному датчику температури - 0,85 кОм і на блакитному 2-контактниому датчику температури антифризу - 0 кОм.
Опір на цих трьох датчиках має бути більш-менш однаковим і припускаю, що може коливатися в межах 0.8-1.2 кОм при температурі навколишнього середовища +20-25 градусів.
Поміняв 2-контактниий датчик температури антифризу й AUDI 80 B4 завелася з півоберта.
Зорієнтувало це відео https://www.youtube.com/watch?v=OtEjh8PNEd4
Діагностика https://www.drive2.ru/l/513807832047419503/
Subscribe to:
Posts (Atom)
