Реле та запобіжники Audi 80 B4 2.0 E 1994

3 [  +/-  ] діагностики

2 [ K/L ] діагностики

1 frei — вільний

      Nebellicht — протитуманні фари (нема)

      E-Lufterrel. — реле вентилятора (нема)

      Relais für Lüfternachlauf — реле роботи вентилятора після поїздки (нема)

      Steuergerät für Scheinwerfer-Reinigungsanlage — омивач фар (нема)

      Entlastungs-Relais — реле розвантаження X-контакта

      214 SHO 89 95 12 40A 12V Relais fur Klimaanlage — реле кондиціонера

204 12V.40A 431951253 H Hornrelais — реле сигналу

Relais für Wegfahrsperre - Brücke für Schaltgetriebe — імобілайзер - міст ручної КП (нема)

229 С 7411 Wisch-Wasch-Intervallrelais — щітки та склоочисник

208 8A0 951253 B 89 9578 000 12V 30/20A PA6 — GF30 Kraftstoffpumpe — паливна помпа

[  Reserve Sicherungen — запасні запобіжники  ]

214 SHO 89 95 12 40A 12V Relais fur Kuhlerlufter (Stufe 1) — вентилятори радіатора (1 швид.)

Під головним щитом запобіжників і реле є додатковий блок реле. На нижній панелі з поличкою водія є наклейка з переліком усіх реле цього блока.

RHD - right hand drive, LHD - left hand drive

214 SHO 89 95 12 40A 12V

217 443 951 253 S

305 443 919 578 J SMK 12V — реле вентиляторів радіатора

60A fuse вентиляторів радіатора

to be continued...

Підключення Fantom FT-228 на Audi 80 B4

Для підключення блока дистанційного керування Fantom FT-228 до центрального замка Audio 80 B4 потрібно врізатися в кабель ЦЗ дверей водія — зелено-синій або зелено-чорний. Див. відео https://www.youtube.com/watch?v=uVfA7xq09X4

1 кінець зелено-чорного кабелю підключаємо до оранжевого кабелю реле закривання (в мене це жовто-червоний кабель, як продовження зелено-чорного - так вийшло), а 2 кінець зелено-чорного кабелю підключаємо до чорно-білого COM реле відкривання. Бажано додати кабель за допомогою гільз, якщо не вистачає.

Жовтий кабель реле закривання в мене пішов на - акумулятора разом із чорним кабелем. - на кузові можна взяти, прикрутивши кабель гайкою до кузова над зелено-чорним кабелем ЦЗ дверей водія.

Жовто-чорний кабель реле відкривання в мене пішов на + акумулятора разом із червоним кабелем, на якому знаходиться запобіжник 15А. Знайдіть плюсовий контакт під панеллю, до якого через клему можна додати кабель.

Оранжево-чорний кабель реле відкривання підключаємо до білого COM реле закривання.

Усе решта дуже просто, крім відкривання багажника. Там потрібне додаткове реле і я цього не робив. Склопідіймачів не маю, тому зелений не чіпав. Корпус Fantom FT-228 я закріпив 2 стяжками на пластиковому кріпленні, де розташовується запобіжник 60А.

Пульти на резонаторі R433.92 Мгц + енкодер V1527 1911P, транзистор M6 (у режимі діода 0.L на E C і на C світить індикатор пульта), транзистор R25 (у режимі діода 0,8 В на E C), резистори 472 (4,64 kOhm), 2 шт. 473 (47 kOhm), 101 (100 Ohm), 103 (10 kOhm), 330 (33,4 Ohm), 334 (326 kOhm) та чорний (0.2-0.4 Ohm) і 2 сірі без маркування (8.8 mOhm, 100 kOhm). Живлення від 2 CR2016 на 3 В.

З 1 пультом проблема - при натисканні мерехтить діод, але нічого не відбувається, яку би кнопку не натиснув. Підозра на резонатор, бо на робочому пульті + контакт 8 mOhm, - контакт 0.L, а неробочий на - контакті 49 mOhm, а на + 4 mOhm. Щоб заміряти опір, треба 1 щуп прикласти до GND (середній контакт на - доріжці), а інший до інших контактів.

Відео англ мовою https://www.youtube.com/watch?app=desktop&v=MTGHyx8Vs44
